Four Station Plastic Thermoforming Machine
SPF-780
Four Station Plastic Thermoforming Machine
A four-station thermoforming machine, also known as a multi-station thermoforming machine, integrates four stations: for...
Captcha Code
Inquiry is being submitted, please wait...
Four Station Plastic Thermoforming Machine
Four Station Plastic Thermoforming Machine
Four Station Plastic Thermoforming Machine
Four Station Plastic Thermoforming Machine
Four Station Plastic Thermoforming Machine
Four Station Plastic Thermoforming Machine
Four Station Plastic Thermoforming Machine
Four Station Plastic Thermoforming Machine
SPF-780

Four Station Plastic Thermoforming Machine

Material
Please Choose
Select All
PET
PP
PS
PLA
Forming Layout
Please Choose
Select All
780*540MM
780*650MM
Max. Forming Depth
Please Choose
Select All
105MM
140MM
Stations
Please Choose
Select All
three stations
four stations
End Product
Please Choose
Select All
lunch box
plate
Fruit Box
bowl
lid
Sauce cup
Sauce cup
egg tray
Compare
Inquiry

Application

Video

Features

Main Technical Parameters

Our Markets
Application
Video
Thermoforming machine produce PP lunch box
Thermoforming Machine produce PET cup lid connect fully automatic stacking and packing machine
Thermoforming machine produces PP boxes this sample is very popular in the South American market
Sinoplast 780*650MM thermoforming machine produce container bowl lid
Sinoplast 780*650mm thermoforming machine produces disposable PET 6-grid food containers
Sinoplast thermoforming machine produce PET Square box
Features

A four-station thermoforming machine, also known as a multi-station thermoforming machine, integrates four stations: forming, punching, cutting, and stacking. The machine is equipped with eight Siemens servo motors, including two 3.5KW servo motors for feeding and stacking, and six 7KW servo motors for the forming, punching, and cutting stations. It adopts an advanced built-in eccentric wheel drive design and thermoforming technology to ensure high-precision cutting and stable operation.



Sinoplast thermoforming machines offer a variety of configurations for customers to choose from, such as German ELSTEIN heating elements, SKF electric oil pumps, forming station servo motor stretching, cutting station mold heating, and other functions.



The machine is equipped with an advanced control system, ensuring users do not need to worry about insufficient lubricating oil during production. After every 1,000 cycles, the machine automatically activates the oil pump for lubrication, preventing damage caused by a lack of lubrication.

Main Technical Parameter

Model

SPM-780E

SPM-780D

SPB-780E

SPB-780D

Station Number

3

4

3

4

Max.Forming Area

780*540MM

780*650MM

Max.Forming Depth

140MM

Suitable Material

PP/PS/PET

Sheet Width

550-820MM

Material Thickness Range

0.15-2.5MM

Max. Sheet Roll Dia.

1200MM

Running Speed

35-40Cycles/min

Forming Station Power

Servo Motor 7 KW*2 pcs

Forming station stretching

Servo Motor 7 KW

Hole Punching Station Power

NONE

Servo Motor 14 KW

NONE

Servo Motor 14 KW

Cutting Station Power

Servo Motor 7 KW*2 pcs

Stacking Station Power

Servo Motor 3.5 KW

Sheet Feeding Method

Servo Motor 5 KW

Air Consumption/Air Pressure

3m3/min，0.6-0.8Mpa



Power Voltage

380V,50Hz 3P

Approx. Machine Weight

17T

21T

17.5T

21.5T
Comparision
WHY CHOOSE US?
CATEGORY
Sinoplast
Others
1. Bearing
Sinoplast：INA bearings imported from Germany are used to ensure the quality of the machine
Other manufacturers：Some ordinary bearings are used
2. Driving structure
Sinoplast：With the drive mode of the built-in eccentric arm, the machine will run faster and more stable during production.
Other manufacturers：The eccentric wheel drive structure is used, and the material is thin
3. Forming stretching
Sinoplast：Forming station We are equipped with a 3.5KW Siemens servo motor for stretching
Other manufacturers：This function is not available
4. Heating element
Sinoplast：We use ELSTEIN heating elements imported from Germany to reduce electricity costs during production
Other manufacturers：Use common brand heating elements
5. Mold cutting with heating function
Sinoplast：The cutting station is equipped with heating function to ensure that the mold is not easily damaged during long-term production
other manufacturers：Not equipped with this function
Machine details
Loading

Cylinder lifting system

Automatic sheet feeding

Able to work with double roll

Max.roll diameter：1200MM

Chains and Rails

Servo motor control

Aluminum alloy strip cooling

Automatic lubrication of the chain（PLC control）

Can stretch the sheet material

Heaters

Oven size: Up and down 13 * 10 MM

Equipped with anti sheet falling sensor

Adopting German Elstein ceramic heater

Forming Station

Maximum forming depth：140 MM

4 pillar supports

Maximum Forming Layout：780*650 MM

Max. stroke:160 MM

Cylinder lock mold

Stacking

Adopting a vacuum suction structure, each air tube is independently connected to the gas source to ensure that one product is not sucked in and affects other products.

Electrical Unit

High quality electronic components ( SIEMENS, OMRON, SEW, SCHNEIDER )

High power cabinet air conditioner
