SPC-780
High Configuration Plastic Thermoforming Machine

Description

The High Configuration Plastic Thermoforming Machine is an ideal choice for customers with high production requirements and large sheet sizes. For such demands, we provide equipment with a 780 x 650 mm molding layout, capable of achieving a maximum speed of 40 molds per minute. However, the operating speed depends on the material and the depth of the product. For example, when using PP material, the speed is usually slower than with PET, as PP requires a higher melting temperature and longer molding time. If the operating speed is too fast, the product may not cool sufficiently, resulting in a white bottom.

Inquire Now
Compare
Download

Watch The Video

High Configuration Plastic Thermoforming Machine
High Configuration Plastic Thermoforming Machine
High Configuration Plastic Thermoforming Machine
High Configuration Plastic Thermoforming Machine
High Configuration Plastic Thermoforming Machine
High Configuration Plastic Thermoforming Machine
Model SPC-780
Max. Forming Area 780*650MM
Max. Forming Depth 105MM
Station Number 4
Features

The High Configuration Plastic Thermoforming Machine is an ideal choice for customers with high production requirements and large sheet sizes. For such demands, we provide equipment with a 780 x 650 mm molding layout, capable of achieving a maximum speed of 40 molds per minute. However, the operating speed depends on the material and the depth of the product. For example, when using PP material, the speed is usually slower than with PET, as PP requires a higher melting temperature and longer molding time. If the operating speed is too fast, the product may not cool sufficiently, resulting in a white bottom.



During the machine production process, the heating of the sheet material has a significant impact on the product forming. If the expected temperature is not reached, it will result in incomplete product molding. Our thermoforming machine is equipped with ELSTEIN heating elements imported from Germany. The use of heating elements from this brand not only reduces the power consumption of the equipment during production, but also provides more precise temperature control, improving the production efficiency of the machine.



The Sinoplast thermoforming machine features four pillars to support each workstation, enhancing stability during operation. It is equipped with advanced control systems, such as PLC control and touch screen operation, which support automation. Due to the varying parameters of each mold group, our engineers save the operating settings in the equipment program after debugging, eliminating the need for customers to readjust them during future startups. The machine also includes safety devices: if the emergency pause button is pressed during improper operation, these devices will automatically activate. For example, if the temperature is set too high, the machine will stop, and the heating box will automatically push out until it cools down before restarting.

Main Technical Parameter

Model

SPM-780E

SPM-780D

SPB-780E

SPB-780D

Station Number

3

4

3

4

Max.Forming Area

780*540MM

780*650MM

Max.Forming Depth

105MM(Can be customized)

Suitable Material

PP/PS/PET

Sheet Width

550-820MM

Material Thickness Range

0.15-2MM

Max. Sheet Roll Dia.

1200MM

Running Speed

35-40Cycles/min

Forming Station Power

Servo Motor 7 KW*2 pcs

Forming station stretching

Servo Motor 3.5 KW

Hole Punching Station Power

NONE

Servo Motor 14 KW

NONE

Servo Motor 14 KW

Cutting Station Power

Servo Motor 7 KW*2 pcs

Stacking Station Power

Servo Motor 3.5 KW

Sheet Feeding Method

Servo Motor 3.5 KW

Air Consumption/Air Pressure

3m3/min,0.6-0.8Mpa



Power Voltage

380V,50Hz 3P

Approx. Machine Weight

17T

21T

17.5T

21.5T

Application
Comparision
WHY CHOOSE US?
CATEGORY
Sinoplast
Others
1. Bearing
Sinoplast:INA bearings imported from Germany are used to ensure the quality of the machine
Other manufacturers:Some ordinary bearings are used
2. Driving structure
Sinoplast:With the drive mode of the built-in eccentric arm, the machine will run faster and more stable during production.
Other manufacturers:The eccentric wheel drive structure is used, and the material is thin
3. Forming stretching
Sinoplast:Forming station We are equipped with a 3.5KW Siemens servo motor for stretching
Other manufacturers:This function is not available
4. Heating element
Sinoplast:We use ELSTEIN heating elements imported from Germany to reduce electricity costs during production
Other manufacturers:Use common brand heating elements
5. Mold cutting with heating function
Sinoplast:The cutting station is equipped with heating function to ensure that the mold is not easily damaged during long-term production
other manufacturers:Not equipped with this function
Machine details
Loading Rack

1.Adopting a double roll feeding design

2.Max. roll diameter: 1200mm

3.Roller lifting function - cylinder

4.Can achieve non-stop machine roll changing

Chains and Rails

Adopting 3.5kw Siemens servo motor control

Sheet edge heater at the feeding point

Automatic chain oiling and lubrication

Water cooled, aluminum chain track

Adopt electric control of track distance

Heating Box

Upper heating power:81.15KW

Lower heating power:81.15KW

Top 13*10, bottom 13*10 (ELSTEIN HEATING ELEMENT)

Forming Station

Maximum forming depth:140mm

Four pillar support

Maximum forming layout: 780 * 650mm

Maximum stroke: 160mm

Driven by two servo motors, one above and one below

The forming station is equipped with a 3.5KW servo motor for stretching

Each Knuckle bearing adopts INA brand

Stacking

Adopting a downward stacking method and paired with a 3.5KW servo motor

Electrical

Using imported brand appliances (Siemens, Schneider, Omron, Delta)

Equipped with high-power air conditioning to ensure optimal heat dissipation performance
